Micro Pressure Transmitter เครื่องส่งสัญญาณความดันขนาดเล็ก
-
-
เครื่องส่งสัญญาณความดันขนาดเล็ก
Measuring range: -0.1~60MPa/ -1bar~600bar
Accuracy: 0.5, 0.25
Singnal output: 4~20mADC; 0~20mA
Power supply: 24VDC
Operating temperature: -50 ~ 80°C
Wetted material: 304, 316L 1Cr18Ni9Ti
Process connection: M20 x 1.5 G1/2" or customize
ส่งฟอร์มขอราคา sales.success.elec@gmail.com
ดาวน์โหลดแคตตาล็อก
แบบฟอร์มขอใบเสนอราคา



Product Instruction
HBY201 type small pressure transmitter used of imported high-precision, high stability of the pressure sensor and high performance special signal processing integrated circuit and converting that pressure signal into two wire 4 ~20mADC output signal.
Product Feature
1. High accuracy, stability and reliability
2. Small size of the pressure transmitter, suitable for narrow space installation
3. Anti-lightning, anti-high-voltage pulse
Applications
Micro pressure transmitter is used in Water, steam, oils, caustic soda, Alcohol, Methanol etc.
